Transform your Ineos Grenadier's factory bumper into a powerful asset with our comprehensive winch kit. This hidden winch mount kit seamlessly integrates into the original bumper shell, preserving the vehicle's stock appearance without requiring any alterations. Featuring the robust Come Up 12.5k SealSlim winch, equipped with 65ft of synthetic line (55ft usable), Increasing the length of the usable line over the factory winch by 83%, ensures you're prepared for any off-road challenge.
Kit Includes
GP Factor Winch Mount, Fairlead, Hardware for Installation, Come up Seal Slim 12.5 RS Winch.
Winch Mount Specifications
Material: Constructed from full 1/4" steel, ensuring durability and strength.
Finish: Coated with Zinc Primer and finished in textured black, providing both corrosion resistance and a sleek appearance.
Fairlead: Includes a proprietary 6061-T6 Billet Aluminum fairlead with Type3 Hardcoat Grey Anodized Finish, combining style with functionality.
Fitment: Compatible with all Ineos Grenadier Models featuring the factory metal bumper. Enhance your vehicle's capability and maintain its original aesthetic with our premium winch kit, designed for reliability and performance in every terrain.
Weight: Mount weights approx 40lbs. Winch weighs approx 75 lbs. Combined 115lbs. net weight gained with this kit is only 85lbs as the factory parts removed weight approx 30lbs.
Winch Mounting Configuration: Foot Foward
Come Up Seal Slim 12.5 RS Winch Specifications
*THIS WINCH IS ONLY AVAILABLE IN THIS KIT AS IT WAS SPECIFICALLY MADE TO FIT THIS KIT, VEHICLE AND PER THE SPECIFICATIONS NEEDED.
- Rated line pull: 5,670 kg / 12,500 lb single line
- Line speed (1st layer): 7.7 mpm / 25.3 fpm 45 A at 12V no load; 0.9 mpm / 3.0 fpm 470 A at 12V full load
- Motor: 3,730 w / 5.0 hp 12V series wound
- Gear ratio: 3-stage planetary 225:1
- Clutch (freespooling): Rotating ring gear
- Brake (outside the drum): Automatic, full load CBS (Cone Brake Structure)
- Winch construction: Aluminum die cast housings with steel drum
- Drum size: 63.5 mm x 227L mm (2.5” x 8.9”L)
- Control: Both built-in digital two way signal wireless remote control and waterproof remote with thermometric indicator LED w/ 5 m (17') cord
- Rope type: Synthetic rope
- Rope size: 65' - (55' Approx Usable)
- Mounting bolt pattern: 254 mm x 114 mm (10” x 4.5”)
- Mounting : Foot forward mounting workable
- Finish : Matte black powder-coated
*Remark: Only foot forward mounting can meet SAE J706
